Features
- The use of constant pressure variable peristaltic helps eliminate the return pipes;
- Touch screen display;
- PLC (programmable logic controller) module, and all parameters are set in the control panel;
- Thermal insulation and heat preservation;
- Fully sealed, operated in negative pressure state;
- Japanese Anest Iwata spray guns are adopted due to its full atomization, large spray range, and adjustable direction without nozzle dripping or clogging;
- This thin film coater has the capability to significantly improve the product yield rate;
Technical Data
| Model | ||||
| Producing capacity (kg/batch) | 5 | 40 | 80 | 150 |
| Speed of drum (r/pm) | 6--30 | 6--30 | 3--15 | 3--15 |
| Power of motor for high efficiency filtering hot air (kW) | 0.75 | 1.1 | 1.5 | 2.2 |
| Power of main motor (kW) | 0.35 | 0.55 | 1.1 | 1.5 |
| Power of motor (dust removing and air exhaust) (kW) | 2.2 | 3 | 3 | 5.5 |
| Dimension (L×W×H) (mm) | 810×710×1410 | 1000×800×1600 | 1250×990×1880 | 1570×1260×2060 |
